SKU: UKC308H-SNR

SNR UKC308H Metric Cast Iron Cartridge Unit with Adaptor Sleeve Mounted and 35mm Bore Insert 34mm Outside Dia - Allow 2-3 Days

SNR UKC308H Metric Cast Iron Cartridge Unit with Adaptor Sleeve Mounted and 35mm Bore Insert 34mm Outside Dia - Allow 2-3 Days
Regular price €116,58 ex VAT
Regular price Sale price €116,58 ex VAT
Sale Sold out

In stock

Price Break
3+ €98,76
4+ €94,77
9+ €92,78
19+ €89,78
49+ €87,79
99+ €82,80
499+ €69,83
999+ €0,00
1999+ €0,00
2999+ €0,00
4999+ €0,00
Quantity
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
Technical
--- Dimensions
Shaft diameter d 35mm
A 34mm
A3 2mm
B1 46mm
d1 58mm
H 120mm
s1 27.5mm
G M6x1
--- Load rating
Dynamic load C 40.56 kN
Static load C0 24 kN
--- Unit information
Operating temperature min. -20°C
Operating temperature max. 100°C
Mass 2.22 kg
