Tapered Roller Bearing Spacers

These tapered roller bearing spacers are commonly used in wheel hubs and differentials, to set precise clearance between paired bearings.

3 products

Loading filters…

Tapered Roller Bearing Spacers

What is a tapered roller bearing spacer?

A tapered roller bearing spacer is a precision ring fitted between two tapered roller bearings to hold them a set distance apart. Because tapered roller bearings are almost always used in pairs, the gap between them decides how much clearance or preload the bearings run with. A spacer of exactly the right width sets that gap accurately, so the bearings run with the correct clearance or preload every time they are fitted.

A standard spaced bearing arrangement has four main parts:

  • Two cone assemblies, which fit onto the shaft
  • Two cups, which fit into the housing
  • A cone spacer, which sits between the two cones on the shaft
  • A cup spacer, which sits between the two cups in the housing (in some arrangements).

The width of the spacer is what sets the clearance or preload.

  • A wider or narrower spacer moves the bearings apart or closer together, which changes the internal clearance.
  • Spacers for matched sets are ground to a precise width, often to within a few microns, so the bearings are set correctly as soon as they are clamped up.

Spacers are usually made from hardened and ground steel, with both faces ground flat and parallel. Some cup spacers also have lubrication holes and a groove, so oil or grease can be fed between the two bearings.

Why are tapered roller bearing spacers essential?

Setting tapered roller bearings by hand, with a nut or shims, takes skill and time, and the result can vary. A precision spacer removes the guesswork: once the spacer is fitted and the bearings are clamped together, the clearance or preload is already correct. This gives a consistent, repeatable setting, which is particularly important in gearboxes, heavy machinery, and production equipment.

Spacers also let bearing sets be supplied ready to fit, with the clearance set in the factory. This saves time during assembly, reduces the risk of mistakes, and helps the bearings reach their full service life.

Typical applications include:

  • Industrial gearboxes and gear drives
  • Differentials and drive axles
  • Pinion and bevel gear shafts
  • Truck and agricultural hubs
  • Rolling mills
  • Pumps and compressors
  • Crushers and mining equipment
  • Machine tool spindles
  • Rail axleboxes

The main types of tapered roller bearing spacers

  • Cone spacers - These sit between the two cones on the shaft. They are the most common type and set the distance between the inner rings.
  • Cup spacers - These sit between the two cups in the housing. They are used where the cups are mounted together, and often have lubrication holes and a groove.
  • Matched spacer sets - These are supplied with a matched pair of bearings, with the cone and cup spacers ground to give a set clearance or preload. They are used for factory-set bearing assemblies.
  • Solid spacers - Rigid spacers ground to an exact width. They can be reused if they are undamaged and used with the same bearings.
  • Collapsible spacers (crush sleeves) - These are designed to compress slightly as the nut is tightened, which sets the preload. They are common on differential pinion shafts and are always replaced when the bearings are disturbed.
  • Shims - Thin rings or washers used alongside a spacer, or on their own, to fine-tune the clearance or preload.

How to choose the right tapered roller bearing spacer?

  • Size and dimensions - The bore must suit the shaft for a cone spacer, or the outer diameter must suit the housing for a cup spacer. The faces must match the bearing faces they sit against.
  • Width - This is the most important dimension, as it sets the clearance or preload. Use the width specified by the bearing or machine maker, or the width supplied with the matched bearing set.
  • Matched set or separate - If the bearings were supplied as a matched set with spacers, replace the bearings and spacers as a set, as the spacer width is matched to those particular bearings.
  • Solid or collapsible - Use the same type as the original design. A collapsible spacer cannot be replaced by a solid one, or the other way round, without changing the setting method.
  • Lubrication - For oil-lubricated arrangements, check whether the cup spacer needs lubrication holes and a groove.

Essential references and specialised ranges

How the numbering works:

Unlike bearings, tapered roller bearing spacers do not have a universal numbering system. They are usually identified by:

The part number of the bearing or bearing set they are used with

The spacer part number given by the bearing or machine manufacturer

The key dimensions: bore, outer diameter, and width

When ordering a replacement, always quote the bearing part numbers and, if possible, the spacer part number or exact width.

Suffixes:

Spacers usually take their codes from the bearing arrangement they are used in:

DB = back-to-back arrangement

DF = face-to-face arrangement

DT = tandem arrangement

Suffix codes vary between manufacturers, so check the supplier’s catalogue for the exact meaning.

FAQ - All you need to know about tapered roller bearing spacers

What does a tapered roller bearing spacer do?

It holds two tapered roller bearings a set distance apart, which sets the clearance or preload in the bearings. This replaces the need to adjust the bearings by hand with a nut or shims.

Can I reuse a spacer when I replace the bearings?

A solid spacer can sometimes be reused if it is undamaged, but its width was set for the original bearings. New bearings may need a different width to give the correct clearance, so the setting should be checked. If the bearings came as a matched set, replace the spacers with the set. Collapsible spacers should never be reused.

What is the difference between a solid spacer and a collapsible spacer?

A solid spacer is rigid and ground to an exact width, so it sets the clearance as soon as the bearings are clamped together. A collapsible spacer, or crush sleeve, is designed to compress as the nut is tightened, which lets the preload be set by measuring the turning torque.

Do spacers need lubrication?

The spacer itself does not need lubricating, but cup spacers with lubrication holes are used to feed oil or grease between the two bearings. Make sure these holes line up with the lubrication supply in the housing.

Click here to learn how to maintain a bearing.

How do I identify a spacer I need to replace?

Check the part number on the spacer, if there is one, and the part numbers on the bearings it fits between. If there are no markings, measure the bore, outer diameter, and width. Measure the width with a micrometer at several points around the spacer, as it must be accurate and the same all the way round.

Click here to learn how to measure a bearing.

How can I tell if a spacer is worn or damaged?

Warning signs include:

  • Wear, scoring, or fretting marks on the faces
  • Faces that are no longer flat or parallel
  • Play developing in the bearings or shaft
  • Bearings running hot because the preload has changed
  • Rust or corrosion on the faces
  • Cracks or distortion in the spacer

Click here to learn how to recognise a failing bearing and tips on how to extend the life of bearings.
