SKU: TMHP30/170-SKF
SKF TMHP Hydraulically Assisted Heavy Duty Jaw Pullers 290-500mm / 11.4-19.7in
SKF TMHP Hydraulically Assisted Heavy Duty Jaw Pullers 290-500mm / 11.4-19.7in
Regular price
€8.550,14
ex VAT
Regular price
Sale price
€8.550,14
ex VAT
In stock
Price Break
10+
€7.609,62
19+
€7.182,12
29+
€7.096,62
39+
€7.011,11
49+
€6.925,61
74+
€6.840,11
99+
€6.412,61
199+
€6.327,10
249+
€6.241,60
499+
€6.156,10
999+
€5.985,10
Couldn't load pickup availability
Description
Description
|
SKF Hydraulically Assisted Heavy Duty Jaw Pullers TMHP Series: The SKF hydraulically-assisted pullers TMHP 15, TMHP 30 and TMHP 50 provide new combined forces of puller power and safety. They are self-centring pullers for the occasions when large forces are inevitable. Pantograph system for ultimate alignment of withdrawal forces and minimised risk of damaging shaft or bearing. Benefits: Extreme forces applied with ease (self-centring, lifting handle, eye bolt, etc.) |
- Brand / Quality:
- SKF - High Quality
Technical
Technical
| Width of Grip | 290-500mm (11.4-19.7 in.) |
|---|---|
| Effective Length of Arms | 170mm (6.7 in.) |
| Claw Height | 35mm (1.4 in.) |
| Stroke | 50mm (2 in.) |
| Maximum Working Pressure Hydraulic Cylinder | 80 Mpa (11 600 psi) |
| Maximum Withdrawal Force | 300 kN (34 US ton) |
