SKU: TMHP15/260-SKF
SKF TMHP Hydraulically Assisted Heavy Duty Jaw Pullers 195-386mm / 7.7-15.2in
SKF TMHP Hydraulically Assisted Heavy Duty Jaw Pullers 195-386mm / 7.7-15.2in
Regular price
€6.063,51
ex VAT
Regular price
Sale price
€6.063,51
ex VAT
In stock
Price Break
10+
€5.396,52
19+
€5.093,35
29+
€5.032,71
39+
€4.972,08
49+
€4.911,44
74+
€4.850,81
99+
€4.547,63
199+
€4.487,00
249+
€4.426,36
499+
€4.365,73
999+
€4.244,46
Couldn't load pickup availability
Description
Description
|
SKF Hydraulically Assisted Heavy Duty Jaw Pullers TMHP Series: The SKF hydraulically-assisted pullers TMHP 15, TMHP 30 and TMHP 50 provide new combined forces of puller power and safety. They are self-centring pullers for the occasions when large forces are inevitable. Pantograph system for ultimate alignment of withdrawal forces and minimised risk of damaging shaft or bearing. Benefits: Extreme forces applied with ease (self-centring, lifting handle, eye bolt, etc.) |
- Brand / Quality:
- SKF - High Quality
Technical
Technical
| Width of Grip | 195-386mm (7.7-15.2 in.) |
|---|---|
| Effective Length of Arms | 264mm (10.4 in.) |
| Claw Height | 30mm (1.2 in.) |
| Stroke | 100mm (3.9 in.) |
| Maximum Working Pressure Hydraulic Cylinder | 80 Mpa (11 600 psi) |
| Maximum Withdrawal Force | 150 kN (17 US ton) |
