SKU: SSUCT.209
SSUCT209 Metric Stainless Steel Take Up Unit Housing with 45mm Bore Stainless Insert
SSUCT209 Metric Stainless Steel Take Up Unit Housing with 45mm Bore Stainless Insert
Regular price
€204,88
ex VAT
Regular price
Sale price
€204,88
ex VAT
Equivalent to: ST45
In stock
Price Break
3+
€156,03
4+
€147,27
9+
€145,51
19+
€143,76
49+
€142,01
99+
€140,25
499+
€131,49
999+
€129,74
1999+
€127,98
2999+
€126,23
4999+
€122,72
Description
Description
|
SSUCT or ST Series Stainless Steel Take up Units: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
Equivalent: ST45
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 45mm
- Style:
- SSUCT
Technical
Technical
| d | 45mm |
|---|---|
| o | 19mm |
| g | 16mm |
| p | 83mm |
| q | 49mm |
| s | 29mm |
| b | 83mm |
| K | 16mm |
| e | 102mm |
| a | 117mm |
| w | 144mm |
| j | 49mm |
| l | 35mm |
| h | 87mm |
| Bi | 49.2mm |
| n | 19mm |
| Weight | 2.4 kg |
| Dynamic load | 2560 kgf |
| Static load | 1810 kgf |
| Rec max speed | 3700 rpm |
