SKU: SSUCF.211-32
SSUCF211-32 Imperial Four Bolt Square Stainless Steel Flange Housing with 2 inch Bore Stainless Insert
SSUCF211-32 Imperial Four Bolt Square Stainless Steel Flange Housing with 2 inch Bore Stainless Insert
Regular price
€131,42
ex VAT
Regular price
Sale price
€131,42
ex VAT
In stock
Price Break
3+
€100,09
4+
€94,46
9+
€93,34
19+
€92,21
49+
€91,09
99+
€89,96
499+
€84,34
999+
€83,22
1999+
€82,09
2999+
€80,97
4999+
€78,72
Description
Description
|
UCF or SF Series Stainless Steel 4 Bolt Square Housings: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 50.8mm = 2 inch
- Style:
- SSUCF
- Bolt Hole Centres:
- 130mm
Technical
Technical
| d | 2 inch |
|---|---|
| a | 162mm |
| e | 130mm |
| i | 25mm |
| g | 20mm |
| L | 43mm |
| S | 19mm |
| Z | 58.4mm |
| Bi | 55.6mm |
| n | 22.2mm |
| Bolt | 16mm |
| Weight | 3.4 kg |
| Dynamic load | 3400 kgf |
| Static load | 2550 kgf |
