SKU: NK20/20-EU
NK20/20 Budget Needle Roller Bearing with Flanges no Shaft Sleeve 20x28x20mm
NK20/20 Budget Needle Roller Bearing with Flanges no Shaft Sleeve 20x28x20mm
Regular price
€7,54
ex VAT
Regular price
Sale price
€7,54
ex VAT
In stock
Price Break
10+
€6,71
19+
€6,33
29+
€6,26
39+
€6,18
49+
€6,11
74+
€6,03
99+
€5,66
199+
€5,58
249+
€5,50
499+
€5,43
999+
€5,28
Couldn't load pickup availability
Description
Description
|
Budget Machined Type Needle Roller with Flanges: Supplied without the inner ring for instances where a mating bearing surface already exists or an inner ring is to be used & has the benefit of flanges in the outer race to compensate for small misalignments and small side loads. Benefits: Economical replacement, needles are retained within machined flange of the outer race. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 20mm
- Outside Diameter:
- 28mm
- Width:
- 20mm
Technical
Technical
| Fw | 20mm |
|---|---|
| D | 28mm |
| C | 20mm |
| Dynamic load C | 16500 N |
| Static load Co | 25500 N |
| Fatigue load limit Pu | 3200 N |
| Speed in grease | 13000 rpm |
| Speed in oil | 19000 rpm |
| r1r2 | 0.3mm |
| Da max | 26mm |
| ra max | 0.3mm |
| Seal | G/SD20x28x4 |
| Weight | 34 g |
