SKU: F2-6-EU
F2-6 Budget Single Thrust Ball Bearing 2x6x3mm
F2-6 Budget Single Thrust Ball Bearing 2x6x3mm
Regular price
€8,26
ex VAT
Regular price
Sale price
€8,26
ex VAT
In stock
Price Break
10+
€7,35
19+
€6,94
29+
€6,86
39+
€6,77
49+
€6,69
74+
€6,61
99+
€6,20
199+
€6,11
249+
€6,03
499+
€5,95
999+
€5,78
Couldn't load pickup availability
Description
Description
Thrust Ball Thrust Bearings: These bearings consist of three parts, a shaft and a housing washer and a caged ball bearing assembly that is sandwiched in between them. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment.
Benefits: Axial loading, ease of mounting and assembly
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 2mm
- Outside Diameter:
- 6mm
- Width:
- 3mm
Technical
Technical
| d | 2mm (+0/0.008mm) |
|---|---|
| D | 6mm (+0/-0.011mm) |
| H | 3mm (+0/-0.075mm) |
| r1r2 min | 0.1mm |
| Dynamic load C | 0.137 kN |
| Static load Co | 0.08 kN |
| Weight | 0.001 kg |
| Lubrication | Light Oil AF2 |
| Material | Balls & Washers, Chrome Steel, Brass or 304 Stainless Steel Cage |
