SKU: BR.101812
BR101812 Machined Type Imperial Needle Roller Bearing Without Inner Ring 5/8x1-1/8x3/4 inch
BR101812 Machined Type Imperial Needle Roller Bearing Without Inner Ring 5/8x1-1/8x3/4 inch
Regular price
€13,89
ex VAT
Regular price
Sale price
€13,89
ex VAT
Equivalent to: HJ101812 HJ-101812 MR10N MR-10-N SJ7133 NCS1012
In stock
Price Break
10+
€10,59
20+
€9,99
30+
€9,87
40+
€9,75
50+
€9,63
75+
€9,52
100+
€8,92
200+
€8,80
250+
€8,68
500+
€8,56
1000+
€8,33
Description
Description
|
Imperial Machined Type Needle Roller with Flanges: Supplied without the inner ring for instances where a mating bearing surface already exists or an inner ring is to be used & has the benefit of flanges in the outer race to compensate for small misalignments and small side loads. Benefits: Economical replacement, needles are retained within machined flange of the outer race. |
Equivalent: HJ101812 HJ-101812 MR10N MR-10-N SJ7133 NCS1012
- Brand / Quality:
- IKO - High Quality
- Inside Diameter:
- 15.88mm = 0.625 (5/8) inch
- Outside Diameter:
- 28.58mm = 1.125 (1-1/8) inch
- Width:
- 19.05mm = 0.75 (3/4) inch
Technical
Technical
| Fw | 5/8 inch |
|---|---|
| D | 1-1/8 inch |
| C | 3/4 inch |
| Dynamic Load Cor | 18900 N |
| Static Load Cr | 19700 N |
| Weight | 0.049 kg |
