SKU: AXK0515TN-MB
Major Brand AXK0515TN Needle Roller Cage 5x15x2mm
Major Brand AXK0515TN Needle Roller Cage 5x15x2mm
Regular price
€5,45
ex VAT
Regular price
Sale price
€5,45
ex VAT
In stock
Price Break
10+
€4,15
19+
€3,91
29+
€3,87
39+
€3,82
49+
€3,77
74+
€3,73
99+
€3,49
199+
€3,45
249+
€3,40
499+
€3,35
999+
€3,26
Description
Description
|
AXK Series Needle Roller thrust Bearings: Needle roller and cage thrust assemblies are a low profile high load thrust bearing assembly and can be used with either the AS, LS or GS series thrust washers which are supplied separately, they are made up of a uniform cage which reliably guides a large quantity of needle rollers, the rollers are slightly relieved towards their outer edge to enable uniform load distribution and prevents any edge damage occurrence. Benefits: Cost effective thrust solution, wide range, low profile, high load bearing |
- Brand / Quality:
- Major Brand - High Quality
- Inside Diameter:
- 5mm
- Outside Diameter:
- 15mm
- Width:
- 2mm
Technical
Technical
| d | 5mm |
|---|---|
| D | 15mm |
| Dw | 2mm |
| Ea | 6mm |
| Eb | 14mm |
| Dynamic load | 4500 N |
| Static load | 9500 N |
| Fatigue load limit Pu | 1000 N |
| Speed in grease | 5000 rpm |
| Speed in oil | 6700 rpm |
| Weight (assembly) | 0.8 g |
| D | 15mm |
