SKU: 53211?EU

53211 Budget Single Thrust Ball Bearing with Spherical Housing Seat U211 55x90x30mm

Name: 53211 Budget Single Thrust Ball Bearing with Spherical Housing Seat U211 55x90x30mm
Brand: Gen
SKU: 53211?EU
Price: 57.45 EUR
Availability: InStock

€57,45 ex VAT

Sale Sold out

In stock

Price Break

10+ €43,76

19+ €41,30

29+ €40,81

39+ €40,31

49+ €39,82

74+ €39,33

99+ €36,87

199+ €36,38

249+ €35,89

499+ €35,40

999+ €34,41

Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment.
Benefits: Axial loading, ease of mounting and assembly

Brand / Quality:: EU Budget - Economy Quality
Inside Diameter:: 55mm
Outside Diameter:: 90mm
Width:: 30mm

Technical

d	55mm
D	90mm
H1	30mm
Dynamic load C	61.8 kN
Static load Co	146 kN
Fatigue load limit Pu	5.4 kN
Minimum load factor A	0.11
Reference speed	2800 rpm
Limiting Speed	4000 rpm
Weight	0.75 kg
Seating Washer	U211
d1	90mm
D1	57mm
D2	72mm
D3	95mm
H	27.35mm
C	9mm
R	72mm
s	35mm
r1r2 min	1mm
da max	76mm
Da max	72mm
ra max	1mm
