SKU: 52212-SKF
SKF 52212 Double Thrust Ball Bearing with Flat Seats 50x95x46mm
SKF 52212 Double Thrust Ball Bearing with Flat Seats 50x95x46mm
Regular price
€150,51
ex VAT
Regular price
Sale price
€150,51
ex VAT
In stock
Price Break
10+
€114,63
19+
€108,19
29+
€106,90
39+
€105,62
49+
€104,33
74+
€103,04
99+
€96,60
199+
€95,31
249+
€94,02
499+
€92,74
999+
€90,16
Share this product
Description
Description
|
SKF Double Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of five parts, a top, bottom and middle plate with annular grooves in them and two caged ball bearing assemblies that are sandwiched in between them. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in two directions. Clearance is provided in the bore of Centre of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 50mm
- Outside Diameter:
- 95mm
- Width:
- 46mm
Technical
Technical
| d | 50mm |
|---|---|
| D | 95mm |
| H | 46mm |
| Dynamic load C | 62.4 kN |
| Static load Co | 150 kN |
| Fatigue load limit Pu | 5.6 kN |
| Minimum load factor A | 0.12 |
| Reference speed | 2200 rpm |
| Limiting speed | 3000 rpm |
| Weight | 1.2 kg |
| D1 | 62mm |
| B | 10mm |
| r1r2 | 1mm |
| r3r4 | 0.6mm |
| da | 60mm |
| Da max | 74mm |
| ra max | 1mm |
| rb max | 0.6mm |
